Baja Designs LP4 Pro LED Auxiliary Light

Small But Mighty

Baja Designs packed all of the power and features of its larger-sized LP lights into its smaller LP4 Pro LED auxiliary lights.

Baja Designs LP4 Pro LED Auxiliary Light

Sold in pairs, the LP4 Pro LED auxiliary light has an output of a total of 8,750 lumens and a 200° spread of useable LED light. Using Baja Designs’ patented Integrated Peripheral Technology (IPT), this light pumps out 7,050 forward-projecting lumens and 1,700 lumens of dedicated peripheral lighting.

Baja Designs LP4 Pro LED Auxiliary Light

To keep your light performing at its highest potential, the LP4 integrates Baja Designs’ proprietary Direct Ducted Cooling (DDC) technology. This feature allows air to travel through the front of the housing and over the rear heat sinks, which can drastically improving cooling capacity and performance.

Baja Designs LP4 Pro LED Auxiliary Light

The LP4 includes amber day-time running light and measures a compact 5.1 x 5.1 x 3.2-inches.

Baja Designs LP4 Pro LED Auxiliary Light

LP4 Pro, Pair Amber Driving/Combo LED Specifications

Forward Projecting Lumens: 7,050 Utilizing 4 LEDs
Forward Projecting Wattage/Amps: 60W / 6.5A
IPT Lumens: 1,700 Utilizing 4 LEDs
IPT Wattage/Amps: 15W / 1.0A
Backlight Wattage/Amps: 4.83W / 0.35A
Dimensions: 5.1″ Height / 5.1″ Width / 3.2″ Depth
Weight: 2.8lbs
LED Life Expectancy: 49,930 Hours
Front Lens: Hardcoated Polycarbonate
Housing: Hard Anodized Machined Aluminum
Bezel: Billet Machined Aluminum
Hardware & Bracket Material: Stainless Steel
Exceeds MIL-STD810G (Mil-Spec Testing)
Built-In Overvoltage Protection
IP69K (Waterproof up to 9ft & Pressure Washable)
IK10 Compliant (Mechanical Impact Testing)
SKU: 297813
Price: $849.95 Pair
